AstralPool Viron Side Discharge Inverter iHP90 Heat Pump

AstralPool Viron Side Discharge Inverter iHP90 Heat Pump

Taxes included. Shipping calculated at checkout.
Quantity

Available In-Store Only

ASTRALPOOL VIRON SIDE DISCHARGE INVERTER IHP90 HEAT PUMP

PERFECT FOR COMPACT SPACES.

In some regions of Australia natural gas heating is unavailable or uneconomical to run. This doesn't mean you have to miss out on having a heated pool to gain a longer swimming season. The AstralPool Heat Pump has been designed to heat your swimming pool using electricity. Based on the same principles employed in air conditioners and refrigerators, the AstralPool Heat Pump extracts the latent heat that exists in the atmosphere around us and delivers its direction into the swimming pool water.

The AstralPool range of Heat Pumps now includes both standard technology and the new Inverter technology. Inverter technology allows the swimming pool heat pump to reach an extremely high COP compared with normal heat pumps in the market. The unique inverter technology reduces the speed of the unit as it reaches the desired temperature. This greatly saves on energy and enables you to enjoy swimming quicker and at a constant temperature.

The Viron Inverter Heat Pump range uses R32 Gas Refridgerant, which offers higher efficiency and longer pipe runs and requires less refrigerant volume per Kw. This means quicker heating times and less energy used to heat up your pool. Reduced electricity consumption by 10% and lower environmental impact.

With the included WiFi module, you can control on the go with your smartphone. Monitor and set your pools temperature even if youre away on a business trip or holiday through your homes WiFi. With the AquaTemp app (available for Android and iOS devices), your pool temperature will always be right at your fingertips wherever you are!

FEATURES

ENERGY EFFICIENT

For every 1 kW of electricity consumed, AstralPool Heat Pumps will collect up to 13 kW of heat from the atmosphere. Sunshine is not necessary and your Heat Pump will continue to heat your pool in air temperatures as low as 7 degrees. So even if the nights are cold, or the days leading up to the weekend are cool, your AstralPool Heat Pump can heat and maintain your pool water temperature at a comfortable swimming temperature.

BUILT FOR AUSTRALIAN ENVIRONMENTS

Unlike many other heat pumps, the corrosion proof titanium heat exchanger is enclosed in a purpose designed and fully injection moulded housing for maximum strength and long life. The fully moulded plastic Heat Pump case is impervious to corrosion and guarantees maximum life regardless of location, “seaside” tropical north or outback.

QUIET COMPRESSOR

A nearly silent compressor moves the refrigerant gas through a coil (called evaporator) through which air is forced and collects heat from the surrounding atmosphere. The now superheated refrigerant gas then passes through a titanium heat exchanger (called a condenser) which transfers the heat into the pool water and the cycle starts again.

ENVIRONMENTALLY FRIENDLY

AstralPool Heat Pumps are an environmentally friendly option to heat your pool. Operating on a similar principle to your refrigerator or air conditioner, Heat Pumps use environmentally friendly refrigerant gas that extracts the latent heat from the air and transfers this heat into the pool water.

INVERTER TECHNOLOGY

AstralPool’s range of Inverter technology heat pumps uses up to 15-30% less power consumption when compared to a non-inverter heat pump.

SILENT MODE

The Inverter technology also reduces noise due to a unique internal ventilation design. The addition of silent mode allows you to operate it at any time without disturbing the neighbours.

WIFI CONTROL AND LCD SCREEN

The Viron range and Top Discharge heat pumps come included with WiFi and an LCD screen for easy intuitive control of settings. WiFi compatibility is also available as an optional add on for all other models.

Warranty

3 years

5 years on compressor.

25 years on titanium heat exchanger warranty. Any damage to the heat exchanger due to incorrect water chemistry is not covered by warranty.

Specifications

Model: VIRON iHPs90

Product Code: WH000618

Operating air temperature (deg.C): -7°C ~ 43°C

Refrigerant: R32

Air 27C / Water 26C / Humidity 80%

  • Heating Capacity (kW): 1.83-8.31
  • COP: 14-5.39

Air 15C / Water 26°C / Humidity 70%

  • Heating Capacity (kW): 1.49-6.82
  • COP: 6.21-4.23

Air 35C / Water 29C / Humidity 70%

  • Cooling Capacity (kW): 1.92-3.5

Power Supply: 220-240V / 50Hz

Power Phase: Single phase

Rated current (A): 9.5

Sound Pressure 1m dBA: 32.2-47.8

Sound Pressure 10m dBA: 307-36.3

Water Connections (mm): 40

Water Flow Volume (m3/hr): 3.7

Water pressure drop (max) (kPa):

Net Dimensions L/W/H (mm): 1000 x 430 x 625

Net weight (kg): 56

Compressor Brand: Mitsubishi
